Power Amplifier – Delta II
Power Amplifier – Delta II
Frequency response
1 Hz - 100 kHz
Weight
36 kg (79 Ib)
Dimensions (W×H×D)
420х191х438
Type
Power Amplifier
Standard
Stereophonic
Class
AB
Signal-to-Noise Ratio, dB
100
THD, %
0,01
Power per channel (2 Оhms), W
750
Power per channel (4 Оhms), W
300
Power per channel (8 Оhms), W
160
Inputs
BSCB/XLR/RCA
Outputs
-
Amplification factor, dB
27
Input Impedance
50 kОhms (RCA), 100 kОhms (XLR)
Input Sensitivity
550 mW (RCA), 850 mW/ (XLR)
Max Input Signal
2 В (RCA), 4 В (XLR)
Output Impedance
-
Output signal
-
Recommended headphones impedance
-
Power Consumption
1500 W max / in standby mode 0,5 W
Damping Factor
> 1000
Additional connections
3.5mm trigger input and output 2 toroidal transformers (2x750VA)
Power Supply
2 toroidal transformers (2×750 VA), 6 stabilized and 2 unregulated sources
Remote control
-
